Description
The Prolite Plug Top range of Automatic Battery Chargers are designed for all lead acid battery types including gel, maintenance free, sealed & LiFePO4. Available with a number of different connectors to suit specific applications, this range is suitable for many applications.
Description
| Model | Input Voltage | Output voltage/current |
Dimensions (L x W x H mm) |
Weight Kg |
Battery range A/h |
| ALPHA 6/12V 500mA | 230 Volt | 6/12volt 500mA | 82 x 65 x 46 | 0.5 | 2A/h-4A/h |
| ALPHA 6V 1Amp | 230 Volt | 6volt 1Amp | 82 x 65 x 46 | 0.5 | 4A/h-8A/h |
| ALPHA 6V 2Amp | 230 Volt | 6volt 2Amp | 82 x 65 x 46 | 0.5 | 8A/h-16A/h |
| ALPHA 12V 3Amp | 110-240 Volt | 12volt 3Amp | 114 x 51 x 33 |
0.22 | 12A/h-24A/h |
Features
Output voltages of 6V or 12V
Input voltage of 110-240V
Output currents up to 3A
Short circuit protection.
3 stage charging.
Reverse polarity protection
Accurate charge status via 3 LEDs
Compact plastic housing
Output connector options
Choice of plug type
